Monday, January 8, 2018

Imei null baseband fix Moto E4

how to fix imei moto e4


How to fix imei null and no baseband on Moto E4 you can learn on this article.
If you're formated you're Moto E4 accidently and you lost imei/baseband you can fix this in just some steps.

Requirements:
MTK VCOM driver - here
Sp Flash tool - here
Baseband package - here ( archive password lenovoroot.com )

Install drivers (with administrative privileges)
Open Sp flash tools
Load scatter file
Load preloader image
Press Ctrl+Alt+V to open advanced mode
Go to window->write memory and another tab with name Write Memory will appear next to Memory test

1
Go to Write memory :
In file path->select efuse.img
Begin address (HEX) : 0x9b80000
Regin: EMMC_USER
Then press button Write memory
Plug USB cable

Proceed with other files in same way

2
In file path->select hw.img
Begin address (HEX) : 0xdd80000
Regin: EMMC_USER
Then press button Write memory
Plug USB cable

3
In file path->select oem.img
Begin address (HEX) : 0xe580000
Regin: EMMC_USER
Then press button Write memory
Plug USB cable

4
In file path->select persist
Begin address (HEX) : 0x6b80000
Regin: EMMC_USER
Then press button Write memory
Plug USB cable

5
In file path->select utags
Begin address (HEX) : 0x9c00000
Regin: EMMC_USER
Then press button Write memory
Plug USB cable

Now you need to have imei and baseband!
Enjoy!



How to enable battery percentage on Moto E4 hidden trick

how to enable battery percentage on moto e4 and most android nougat


On yours Moto E4 certainly missing battery percentage and it's as well as on most devices with pure Android Nougat version.Here's the hidden trick of how to enable battery percentage without any installation or flashing some mods.

Pull down status bar
Go to quick settings on right top corner
Hold on your finder under quick settings gearwheel until it moving after 20sec remove your finger and will be appear notification Congrats! System UI Tuner has been added to Settings! like on next screen shot



Scroll down in settings and look for System UI Tuner


Scroll again down to battery percentage in System UI Tuner


Then select Always Show percentage


And final result will be like this screen


Sunday, January 7, 2018

How to remove FRP lock on Moto E4

remove frp lock bypass frp moto e4

If you're have a locked device by FRP for some reason like forgot device Google account and you do a force factory reset via Android recovery now you can remove this lock by doing some special tricks.


Method 1

Requirements:
MTK VCOM driver - here
Sp Flash tool - here
package for sp flash tool (with FRP image, preloader, scatter file ) - here

Install drivers (with administrative privileges)
Open Sp flash tools
Load scatter file
Load preloader image
Press Ctrl+Alt+V to open advanced mode
Go to window->write memory and another tab with name Write Memory will appear next to Memory test
Go to Write memory :
In file path->select FRP.img
Begin address (HEX) : 0x9c80000
Regin: EMMC_USER
Then press button Write memory
FRP will be flashed for 2seconds and you can boot device
Now you have unlocked device without FRP lock!
Enjoy!



Method 2

Requirements:
MTK VCOM driver - here
Sp Flash tool - here

Install drivers (with administrative privileges)
Open Sp flash tools
Go to format section:
Press Manual Format flash
Set these values:
- Region: EMMC_USER
- Begin address (HEX): 0x9c80000
- Format lenght (HEX): 0x100000
And press start then plug USB cord to PC and Moto E4
After formating this region you can start device and now you have removed FRP
You can use device!




Tuesday, December 26, 2017

LineageOS 14.1 for Moto E4 Qualcomm variant

lineageos 14 rom for moto e4 qualcomm
Here's the LineageOS 14.1 ROM for Qualcomm variant of Moto E4.
It's unofficial build but working bug less, fast & smooth.

Requirements:
- Moto E4 Unlocked bootloader ( if already locked bootloader check out this post )
- TWRP recovery Moto E4 Qualcomm variant ( if already haven't check out this post )

Installation steps:
Download latest build from 10.17.2017 - here
  1. Boot into TWRP recovery by holding VOL Down + Power button on power off state
  2. Go to recovery with volume rocker then enter with Power button
  3. In TWRP go to Wipe -> advanced wipe -> then check Dalvik, System, Cache, Data and swipe to wipe
  4. Go back to install and find LineageOS zip archive then swipe to install
  5. Wait to process finish Moto E4 will be restarted automatically.
  6. First boot can take more time than usual just wait be patient!
  7. Enjoy of fastest & smoothest ROM on Moto E4.
Optional: Download Gapps here then flash with TWRP recovery

Video tutorial & quick look

LineageOS 14.1 for Moto E4 Mediatek

 lineageos 14 rom for moto e4 mediatek

Here's the CyanogenMod based custom ROM LineageOS compiled for Moto E4 and available right now.
It's daily ROM with even no bugs, fully optimized and providing super fast & smooth work.
Comes with amazing tweaks about battery, screen, CPU, GPU etc. and unique features that stock ROM never provides also it's tiny in size.I think it's fastest & smoothest custom ROM for Moto E4.

Requirements:
- Moto E4 Unlocked bootloader ( if already locked bootloader check out this post )
- TWRP recovery Moto E4 ( if already haven't check out this post )

Installation steps:
Download latest build from 12.11.2017 (with december security patch) - here
  1. Boot into TWRP recovery by holding VOL Down + Power button on power off state
  2. Go to recovery with volume rocker then enter with Power button
  3. In TWRP go to Wipe -> advanced wipe -> then check Dalvik, System, Cache, Data and swipe to wipe
  4. Go back to install and find LineageOS zip archive then swipe to install
  5. Wait to process finish Moto E4 will be restarted automatically.
  6. First boot can take more time than usual just wait be patient!
  7. Enjoy of fastest & smoothest ROM on Moto E4.
Optional: Download Gapps here then flash with TWRP recovery
Video tutorial & quick look

Wednesday, December 13, 2017

dotOS custom ROM for Moto E4


dotos rom for moto e4 woods
dotOS is custom ROM which provides performance and stability including georgeos features and extras.
It's at stable condition and available for Moto E4 with officially OTA updates you can download newly released version throught system settings updates option.Some of general version of Moto E4 uses quad-core CPU MTK6737 or MTK6735 which is low-end CPU even with pure Android official ROM on Moto E4 there's feels some lag and slows but dotOS is more optimized and clean from useless apps & features therefore you can't meet any slows or lag, also it's slim size than official Moto E4 ROM just only 350mb.If you know performance and fast speed of CyanogenMod, dotOS is alternative of CyanogenMod ROM.

Some of features of dotOS:
Stability and Performance
Lagfree with High Performance Results
Clutterless UI
Perfect Interface for every User
Enhanced default apps
Redesigned settings and QS panel
Full OMS support
Colour Engine Support

Download dotOS v1.1 (07.12.2017) - download

Installation:
Pre-requirements

  1. Download ROM to internal storage or sdcard
  2. Boot into TWRP recovery
  3. Go to advanced wipe:
  4. data,cache,system,dalvik
  5. Go back go to install
  6. Choose dotos rom zip file
  7. Swipe to install
  8. Wait to installation finish
  9. Reboot to system
  10. First boot can take some more time just wait!
  11. Enjoy!
official dotos ota updates page



TWRP recovery for Moto E4

twrp recovery for moto e4

 If you already unlocked bootloader of your Moto E4 you can flash TWRP custom recovery if have not unlocked bootloader check out this tutorial How to unlock bootloader of Moto E4.


TWRP recovery for Moto E4 Mediatek variant - download
TWRP recovery for Moto E4 Qualcomm variant - download

There's two ways of booting into bootloader:

First:
If you're on Android
Turn usb debugging from developer options
Open cmd and type adb reboot bootloader ( rebooting into bootloader )

Second:
You can boot into bootloader on switched off phone follow these steps:
1.Switch off completely Moto E4
2.Hold Vol down + Power button for 5sec. until you see Android robot
3.Navigate to Meta mode with volume rocker then enter with power button
4.Plus USB cord to PC and Moto E4

5.Download TWRP recovery
6.Open cmd
7.Type fastboot flash recovery c:/recovery.img (if you don't know where's fastboot folder move recovery.img into c: partition)
8.On cmd needs to be appear something like this:
- Writing recovery
- OKAY
- Finished! Video tutorial

Sunday, December 10, 2017

Lenovo Android Secret Codes

lenovo secret codes


Lenovo Vibe secret codes

Lenovo Hidden menu
Lenovo Hidden secret codes


####0000# - software version
####1111# - factory test ( screen,colors,sound,vibration,buttons )
####2222# - serial number
####3333# - doesn't known
####4444# - phone automatically restart.
####7777# - factory reset
####5993# - another code for software version checking
####8375# - detailed infomation about software,cpu,hw,kernel,build type
####537999# - open Developer options
####266344# - Idea friend configuration
####6020# - change region Lenovo code
*#*#3646633#*#* - Mediatek Engineer mode

How to unlock bootloader Moto E4

how to unlock bootloader moto e4

 Here's the tutorial of how to can be unlocked bootloader of Moto E4 it don't need from oem key for unlocking.
Before everything I've recommend to make a full backup of your stock firmware check this post.

Requirements:
- USB cable
- Basic knowledge of command-promt commands
- ADB/Fastboot minimal drivers - download
- Moto E4 drivers - download

1. First prepare Moto E4 to work with adb
2. Go to settings -> About phone -> tap 7times on build.number until appeared message You're now a developer!.
3. Then go back to root of settings and at the end needs to be unlocked new menu Developer options then open it.
4. Locate Oem unlocking and enable.
5. Locate Usb debugging and enable.
6. Plug USB cord to PC and phone.
7. In PC open command-promnt (you can easy open with run/windows button+R/ and type cmd).
8. Type adb devices and on phone screen needs to be appear message Allow usb debugging.
if showing something like z23436556 and attached you're on right way.
9. Type adb reboot bootloader (phone will rebooted into bootloader).
if on phone screen appeared on left bottom corner fastboot mode >> you're on fastboot mode for unlocking bootloader proccess.
10.Type fastboot devices ( if showing blank you need to install drivers from device manager for thus follow these steps).
- devicemanager can be accessed from run command type devmgmt.msc
- locate Android on other devices section
- then right click and Update driver software... -> browse my computer for driver software -> let me pick from a device list of device drivers on my computer -> Android device - > Motorola ADB interface and confirm installion of driver
11.Type in cmd fastboot oem unlock.
12. On Moto E4 screen will appear message to confirm unlocking of bootloader press VOL UP for confirmation.
13. If unlocking proccess started you will see something like this on command-promt:
- Start unlock flow
- Total time.31.600s
14.If everything goes good on Moto E4 screen will appear recovery, bootloader, reboot.
15.That's it Moto E4 bootloader was unlocked without oem key providing!
If you try to boot with unlocked bootloader you can't boot it you need to flash kernel which works with unlocked bootloader therefore you can use stock unlocked rom.

Video tutorial

How to backup whole stock firmware of Moto E4 on locked bootloader



 Here's the tutorial of how to backup stock firmware of Moto E4 (Mediatek version) but probably won't work with Qualcomm version.
Before unlocking bootloader you can backup whole Moto E4 firmware including oem key, bootloader and other partitions for later which you can restore whole stock firmware as well as you bought the device and restore to original state for warranty purposes.

Requirements:
- USB cable

- MTK VCOM drivers - download
- Moto E4 driver - download
- Mircale Box v.2.27a - download (archive pass naijanrom.com)

1. Install MTK VCOM driver as administrator


2. Install Moto E4 driver



3. Unpack Miracle Box
4. Open Miraclebox loader
By default it needs to be in MTK tab then Service to be checked at Read
5. Go to BOOT SELECT and choose 8th boot (MT65xx & MT67xx/8127)
6. Go to below and check SAVE AS SCATTER FILE


7. Next plug USB cord to PC then hold immediately VOL UP and plug microusb side to Moto E4 when you hear the usb plugged sound press Start button on Miraclebox loader
8. Then on screen will appear which partitions to be save check all partition without USRDATA and CACHE


9. And choose path where to be saved firmware


Wait to process finish and reboot phone by holding all buttons for 20sec. or remove battery!
You now need to have whole firmware in your PC.


Video tutorial backup Moto E4 with Miraclebox loader
